MP..系列平行轴斜齿轮减速机选型参数表(电机功率为1.5KW)
微信：grove_company
|
电动机功率
(kW) |
输出转数
(r/min) |
输出转矩
(N・m) |
传动比
(i) |
使用系数
(fB) |
机型号 |
电机极数 |
重量
(kg) |
传真：0312-6784733
|
1.5 |
0.58
0.72
0.83
0.96
1.1
1.2
1.5
1.7
1.8
2.8
3.1 |
23582
18780
16369
14173
12948
11217
9225
8214
7368
4860
4355 |
2426
1932
1684
1458
1332
1154
949
845
758
500
448 |
0.80
0.91
1.04
1.21
1.32
1.52
1.85
2.1
2.3
3.5
3.9 |
MP157MD97
MPF157MD97
MPA157MD97
MPAF157MD97 |
4P
4P
4P
4P |
1025
1125
1005
1055 |
|
0.85
1.0
1.2
1.3
1.5
1.7
2.0
2.1 |
15932
13366
11762
10663
9011
7951
6970
6416 |
1639
1375
1210
1097
927
818
717
660 |
0.80
0.85
0.97
1.07
1.27
1.43
1.64
1.78 |
MP127MD77
MPF127MD77
MPA127MD77
MPAF127MD77 |
4P
4P
4P
4P |
640
690
605
645 | |
|
1.4
1.6
1.9
2.2 |
9516
8330
7310
6114 |
979
857
752
629 |
0.80
0.88
1.00
1.19 |
MP107MD77
MPF107MD77
MPA107MD77
MPAF107MD77 |
4P
4P
4P
4P |
390
415
375
395 | |
|
2.5
2.8
3.2
3.7 |
5453
4783
4277
3645 |
561
492
440
375 |
1.34
1.56
1.71
2.0 |
MP107MD77
MPF107MD77
MPA107MD77
MPAF107MD77 |
4P
4P
4P
4P |
390
415
375
395 | |
|
2.6
3.0
3.5
3.9 |
5171
4549
3917
3509 |
532
468
403
361 |
0.80
0.90
1.04
1.16 |
MP97MD57
MPF97MD57
MPA97MD57
MPAF97MD57 |
4P
4P
4P
4P |
278
313
273
293 | |
|
4.1
4.7
5.6
|
3295
2906
2430
|
339
299
250
|
0.86
0.98
1.17
|
MP87MD57
MPF87MD57
MPA87MD57
MPAF87MD57 |
4P
4P
4P
4P |
183
198
173
188 | |
|
2.8
3.2
3.4
3.8 |
5161
4520
4250
3787 |
248.60★
217.70★
204.70★
182.40★ |
1.41
1.61
1.72
1.93 |
MP107
MPF107
MPA107
MPAF107 |
8P
8P
8P
8P |
357
382
342
362 | |
|
3.7
4.2
4.5
5.0 |
3871
3390
3187
2840 |
248.60★
217.70★
204.70★
182.40★ |
1.88
2.2
2.3
2.6 |
MP107
MPF107
MPA107
MPAF107 |
6P
6P
6P
6P |
346
371
331
351 | |
|
3.3
3.7
4.0
4.9
5.4 |
4287
3844
3572
2918
2664 |
275.30★
246.90★
229.40★
187.40
171.10 |
0.95
1.06
1.14
1.40
1.53 |
MP97
MPF97
MPA97
MPAF97 |
6P
6P
6P
6P |
256
291
251
271 | |
|
5.1
5.7
6.1
7.5
8.2 |
2817
2526
2347
1918
1751 |
275.28★
246.87★
229.38★
187.44
171.13 |
1.45
1.62
1.74
2.1
2.3 |
MP97
MPF97
MPA97
MPAF97 |
4P
4P
4P
4P |
250
285
245
265 | |
|
5.2
5.5
6.2
7.0
8.0
9.0
11
11
13 |
2760
2622
2319
2042
1795
1595
1358
1292
1142 |
269.75★
256.22★
226.68★
199.56★
175.45★
155.93
132.75
126.26
111.59 |
1.03
1.09
1.23
1.40
1.59
1.79
2.1
2.2
2.5 |
MP87
MPF87
MPA87
MPAF87 |
4P
4P
4P
4P |
155
170
145
160 | |
|
8.3
9.8
11
12
13
15
17
19
22
23
25
28
32
37
41
44 |
1723
1456
1313
1192
1112
975
862
767
657
615
576
509
453
384
346
328 |
168.38★
142.27★
128.35
116.49★
108.68★
95.31
84.26
74.98
64.22★
60.07
56.32
49.79
44.30
37.55
33.79
32.10 |
0.83
0.98
1.09
1.20
1.28
1.46
1.65
1.86
2.2
2.3
2.5
2.8
3.1
3.7
4.1
4.3 |
MP77
MPF77
MPA77
MPAF77 |
4P
4P
4P
4P |
103
114
100
106 | |
|
16
17
21
22
25
27
33 |
915
832
680
638
563
526
428 |
89.42
81.29
66.45
62.33
55.03
51.44★
41.81 |
0.85
0.94
1.15
1.22
1.38
1.48
1.82 |
MP67
MPF67
MPA67
MPAF67 |
4P
4P
4P
4P |
71
77
68
74 | |
|
36
38
41
43
50
57 |
401
376
353
332
289
253 |
39.16
36.73
34.49
32.43
28.26
24.75 |
1.85
2.1
1.99
2.3
2.7
3.1 |
MP67
MPF67
MPA67
MPAF67 |
4P
4P
4P
4P |
71
77
68
74 | |
|
24
28
32
38
41
47 |
602
503
449
382
353
303 |
58.87★
49.17
43.90
37.32
34.49
29.59 |
0.95
1.13
1.27
1.49
1.35
1.71 |
MP57
MPF57
MPA57
MPAF57 |
4P
4P
4P
4P |
60
66
60
65 | |
|
33
39
41
44
48
51
54
65
70
80
86
98 |
435
366
345
322
301
282
264
221
205
179
167
147 |
42.47★
35.73
33.76★
31.46★
29.40★
27.53★
25.84★
21.56
20.07★
17.47
16.33
14.32 |
0.87
1.04
1.10
1.18
1.26
1.35
1.44
1.72
1.85
2.1
2.3
2.6 |
MP47
MPF47
MPA47
MPAF47 |
4P
4P
4P
4P |
50
53
50
52 | |
|
67
76
81
97
108
119
132
153
177
203
232
263
279
333
374 |
213
187
176
148
133
120
108
94
81
70
62
55
51
43
38 |
20.82★
18.31★
17.22★
14.49
13.00
11.72
10.60
9.17★
7.90★
6.88★
6.04
5.33
5.01
4.20
3.75 |
0.89
1.01
1.08
1.28
1.43
1.51
1.62
1.77
2.0
1.89
2.1
2.2
2.2
2.4
2.6 |
MP37
MPF37
MPA37
MPAF37 |
4P
4P
4P
4P |
44
46
44
45 |
