格鲁夫丝杆升降机
|
型号 |
公称功率
/KW |
许用转矩
/N・m |
质量
/Kg |
A |
B |
C |
d |
E |
b |
t1 |
H |
d1 |
L1 |
h |
L |
J |
|
JZT11-4 |
0.6 |
3.9 |
65 |
190±0.7 |
230±1.05 |
37 |
18 |
40 |
6 |
14.5 |
112 |
12 |
237 |
257 |
532 |
276 |
|
JZT12-4 |
0.8 |
5.2 |
70 |
538 | ||||||||||||
|
JZT21-4 |
1.1 |
7.2 |
90 |
216±0.7 |
238±1.05 |
45 |
22 |
50 |
6 |
18.5 |
132 |
12 |
265 |
303 |
588 |
314 |
|
JZT22-4 |
1.5 |
9.8 |
100 |
618 | ||||||||||||
|
JZT31-4 |
2.2 |
14.3 |
140 |
254±1.05 |
265±1.05 |
41 |
28 |
60 |
8 |
24 |
160 |
15 |
310 |
365 |
671 |
366 |
|
JZT32-4 |
3.0 |
19.5 |
150 |
691 | ||||||||||||
|
JZT41-4 |
4.0 |
26.0 |
205 |
278±1.05 |
325±1.4 |
39 |
32 |
80 |
10 |
27 |
180 |
15 |
350 |
415 |
810 |
402 |
|
JZT42-4 |
5.5 |
35.8 |
215 |
835 | ||||||||||||
|
JZT51-4 |
7.5 |
46.8 |
235 |
318±1.05 |
340±1.4 |
39 |
38 |
80 |
10 |
33 |
200 |
19 |
376 |
596 |
866 |
442 |
|
JZT52-4 |
10 |
62.5 |
250 |
896 | ||||||||||||
|
JZT61-4 |
13 |
82 |
380 |
368±1.4 |
419±1.75 |
40 |
42 |
110 |
12 |
37 |
225 |
20 |
450 |
|
940 |
508 |
|
JZT62-4 |
17 |
107 |
400 |
980 |
