机座号 |
a1
b1 |
c1
e1 |
h1
f1 |
O7 |
O9 |
P3 |
S1
V1 |
d
|
l
l12 |
k1
k2 |
t
u |
M2 |
|
YCPJ130F |
200
130 |
12
165 |
130
3.5 |
172 |
165 |
285 |
(4孔)11
85 |
30k6
|
60
50 |
107
40 |
33
8 |
M8 |
|
YCPJ160F |
250
180 |
15
215 |
160
4 |
212 |
205 |
351 |
(4孔)14
101 |
40k6
|
80
70 |
139
48 |
43
12 |
M10 |
|
YCPJ208F |
250
180 |
15
215 |
208
4 |
260 |
250 |
442 |
(4孔)14
124 |
50k6
|
100
80 |
162
61 |
53.5
14 |
M12 |
|
YCPJ255F |
350
250 |
20
300 |
255
5 |
315 |
270 |
540 |
(4孔)18
151 |
60m6
|
120
110 |
184
65 |
64
18 |
M12 |
|
YCPJ290F |
450
350 |
22
400 |
290
5 |
380 |
345 |
628 |
18
182 |
70m6
|
140
125 |
265
85 |
74.5
20 |
M12 |
|
YCPJ358F |
450
350 |
22
400 |
358
5 |
464 |
394 |
763 |
18
225 |
90m6
(80m6)
|
170
160 |
275
85 |
95
(85)
25
(22) |
M16 |
