型号 |
安装尺寸 |
轴伸尺寸 |
外形尺寸 | ||||||||||
|
H0 |
B0
a2 |
A0 |
d0
h |
d |
b
c |
L3 |
M |
B |
q
L1 |
H |
W
f4 |
h1
A | |
|
WKA37 |
100 |
60
35 |
117 |
M10
20 |
30H7 |
8
33.3 |
105 |
M10 |
95 |
71
142 |
165 |
60
2.5 |
8.5
147 |
|
WKA47 |
112 |
70
40 |
140 |
M10
20 |
35H7 |
10
38.3 |
130 |
M12 |
108 |
75
170 |
185 |
75
2.5 |
7.2
175 |
|
WKA57 |
132 |
88
47 |
152 |
M12
20 |
40H7 |
12
43.3 |
142 |
M16 |
122 |
98
175 |
215 |
83
3 |
13.1
182 |
|
WKA67 |
140 |
88
42 |
152 |
M12
25 |
40H7 |
12
43.3 |
156 |
M16 |
124 |
95
183 |
230 |
90
3.5 |
20
207 |
|
WKA77 |
180 |
102
48 |
170 |
M16
32 |
50H7 |
14
53.8 |
183 |
M16 |
146 |
109
203 |
288 |
105
4 |
31.3
225 |
|
WKA87 |
212 |
118
65 |
225 |
M16
32 |
60H7 |
18
64.4 |
210 |
M20 |
190 |
132
258 |
340 |
120
4 |
24
300 |
|
WKA97 |
265 |
160
83 |
248 |
M20
36 |
70H7 |
20
74.9 |
270 |
M20 |
240 |
158
277 |
414 |
150
4 |
32.3
328 |
|
WKA107 |
315 |
190
100 |
290 |
M24
44 |
90H7 |
25
95.4 |
310 |
M24 |
266 |
199
354 |
505 |
175
2.5 |
52
400 |
