型号 |
安装尺寸 |
轴伸尺寸 |
外形尺寸 | ||||||||||
|
A1
A0 |
a2
B0 |
S1
H0 |
L5 |
d |
c
b |
L8
L9 |
M1 |
f |
h1
n |
O7
P3 |
O8
d7 |
k | |
|
WFAB37 |
22.5
77 |
31
115 |
M8
74 |
11 |
30H7 |
33.3
8 |
105
17 |
M10×25-8.8 |
135 |
112
20 |
169
250 |
120
45 |
116 |
|
WFAB47 |
34
93 |
43
145 |
M10
83 |
15 |
35H7 |
38.3
10 |
130
22 |
M10×25-8.8 |
165 |
125.1
20 |
186
242 |
150
50 |
139 |
|
WFAB57 |
33.5
102 |
55
170 |
M12
100 |
17 |
40H7 |
43.3
12 |
142
29 |
M16×40-8.8 |
195 |
136
25 |
200
317 |
166
55 |
149 |
|
WFAB67 |
38
112 |
60
190 |
M12
97 |
17 |
40H7 |
43.3
12 |
156
29 |
M16×40-8.8 |
215 |
163.7
25 |
218
343 |
180
55 |
162 |
|
WFAB77 |
37.5
140 |
70
240 |
M16
118.7 |
26 |
50H7 |
53.8
14 |
183
32 |
M16×45-8.8 |
275 |
206.3
35 |
279
426 |
210
70 |
193 |
|
WFAB87 |
43
165 |
100
310 |
M16
152 |
26 |
60H7 |
64.4
18 |
210
36 |
M20×50-8.8 |
350 |
246.7
40 |
331
531 |
240
85 |
224 |
|
WFAB97 |
49.5
205 |
120
350 |
M20
178 |
28 |
70H7 |
74.9
20 |
270
34 |
M20×50-8.8 |
400 |
285
50 |
400
623 |
300
95 |
272 |
|
WFAB107 |
84
220 |
125
400 |
M24
200 |
36 |
90H7 |
95.4
25 |
310
40 |
M24×60-8.8 |
460 |
332.4
60 |
450
717 |
350
120 |
321 |
|
WFAB127 |
85
270 |
142
450 |
M300
236 |
45 |
100H7 |
106.34
28 |
370
38 |
M24×60-8.8 |
520 |
382.6
70 |
530
856 |
410
135 |
376 |
|
WFAB157 |
121
310 |
170
540 |
M36
286 |
55 |
120H7 |
127.4
32 |
457
36 |
M24×60-8.8 |
620 |
447
80 |
660
1021 |
500
155 |
455 |
