BAF机型安装结构尺寸
|
机型号 |
D |
C1 |
D1 |
f0 |
i2 |
w |
t |
d0 |
L2 |
u |
D2 |
d |
M |
|
BAF37 |
160 |
10 |
130 |
3.5 |
24 |
60 |
33.3 |
4-φ9 |
105 |
8 |
110h7 |
30H7 |
用
户
自
配 |
|
BAF47 |
200 |
12 |
165 |
3.5 |
25 |
75 |
38.3 |
4-φ9 |
132 |
10 |
130h7 |
35H7 | |
|
BAF67 |
250 |
15 |
215 |
4 |
23 |
90 |
43.3 |
4-φ13.5 |
156 |
12 |
180h7 |
40H7 | |
|
BAF77 |
300 |
16 |
265 |
4 |
37 |
105 |
53.8 |
4-φ13.5 |
183 |
14 |
230h7 |
50H7 | |
|
BAF87 |
350 |
18 |
300 |
5 |
30 |
120 |
64.4 |
4-φ18 |
210 |
18 |
250h7 |
60H7 | |
|
BAF97 |
450 |
22 |
400 |
5 |
41.5 |
150 |
74.9 |
8-φ18 |
270 |
20 |
350h7 |
70H7 | |
|
BAF107 |
450 |
22 |
400 |
5 |
41 |
175 |
95.4 |
8-φ18 |
313 |
25 |
350h7 |
90H7 | |
|
BAF127 |
550 |
25 |
500 |
5 |
51 |
205 |
106.4 |
8-φ18 |
373 |
28 |
450h7 |
100H7 | |
|
BAF157 |
660 |
28 |
600 |
6 |
60 |
250 |
127.4 |
8-φ22 |
460 |
32 |
550h7 |
120H7 |
注：其它尺寸 其中BAF37―BAF107参见BA型BAF127―BAF157参见B型
