S系列斜齿轮―蜗杆减速机外形及安装方位和外形及安装尺寸 格鲁夫减速机
格鲁夫
|
型 号 |
安 装 尺 寸 |
轴 伸 尺 寸 |
外 形 尺 寸 | ||||||||||||||||||||
|
H0 |
A0 |
B0 |
A1 |
a1 |
a2 |
L0 |
d0 |
d |
ι |
b |
c |
S |
L1 |
A |
B |
W |
H1 |
H2 |
H3 |
h1 |
h2 |
T | |
|
S 32 |
80 |
63 |
90 |
15 |
35 |
40 |
55 |
9 |
20k6 |
40 |
6 |
22.5 |
M8 |
153 |
90 |
110 |
100 |
3 |
143 |
― |
10 |
10 |
32 |
|
S 42 |
100 |
80 |
100 |
15 |
35 |
35 |
75 |
11 |
25k6 |
50 |
8 |
28 |
M8 |
190 |
112 |
124 |
115 |
7 |
163 |
― |
15 |
14 |
34 |
|
S 52 |
112 |
100 |
110 |
19 |
45 |
35 |
80 |
11 |
30k6 |
60 |
8 |
33 |
M8 |
201 |
145 |
136 |
134 |
12 |
190 |
― |
16 |
16 |
35 |
|
S 62 |
140 |
130 |
130 |
19 |
60 |
40 |
106 |
14 |
35k6 |
70 |
10 |
38 |
M10 |
248 |
195 |
160 |
160 |
18 |
231 |
277 |
20 |
18 |
38 |
|
S 72 |
180 |
135 |
150 |
30 |
75 |
70 |
125 |
18 |
45k6 |
90 |
14 |
48.5 |
M10 |
308 |
216 |
185 |
195 |
29 |
291 |
336 |
25 |
25 |
45 |
|
S 82 |
225 |
180 |
200 |
35 |
92 |
82 |
150 |
22 |
60m6 |
120 |
18 |
64 |
M12 |
372 |
260 |
250 |
255 |
30 |
372 |
434 |
34 |
30 |
55 |
|
S 92 |
280 |
235 |
250 |
30 |
115 |
90 |
180 |
26 |
70m6 |
140 |
20 |
74.5 |
M12 |
438 |
320 |
300 |
295 |
55 |
502 |
564 |
40 |
35 |
65 |
