规格 |
额定输出转矩MN2（KNm）
n1=1000 1/min的计算值 | ||||||||||||||
|
公称传动比iN | |||||||||||||||
|
MC2P |
7.1 |
8 |
9 |
10 |
11.2 |
12.5 |
14 |
16 |
18 |
20 | |||||
|
02
03 |
6.6
8.5 |
6.4
8.9 |
6.0
8.6 |
6.8
9.4 |
6.5
9.3 |
6.8
8.2 |
6.5
9.4 |
6.2
8.8 |
6.2
8.8 |
5.7
8.2 | |||||
|
04
05 |
10.7
15.0 |
11.2
15.5 |
11.6
15.9 |
12.0
16.6 |
12.5
16.9 |
12.2
15.2 |
13.0
17.0 |
12.0
16.2 |
12.0
16.2 |
11.5
15.2 | |||||
|
06
07 |
17.2
22.2 |
196
23.8 |
20.4
27.7 |
19.0
24.2 |
21.8
26.7 |
20.0
25.5 |
21.8
28.6 |
21.3
29.3 |
21.4
29.4 |
19.8
27.4 | |||||
|
08
09 |
28.5
36.2 |
32.1
41.8 |
33.6
45.9 |
31.3
39.6 |
35.2
45.8 |
33.2
41.5 |
37.4
48.1 |
37.9
51.4 |
38.1
51.7 |
35.6
48.4 | |||||
|
| |||||||||||||||
|
MC3P |
22.5 |
25 |
28 |
31.5 |
35.5 |
40 |
45 |
50 |
56 |
63 |
71 |
80 |
90 |
100 |
112 |
|
02
03 |
6.8
9.1 |
6.5
9.3 |
6.1
8.7 |
6.5
9.3 |
6.1
8.8 |
7.0
9.4 |
6.5
9.5 |
6.2
8.9 |
6.5
9.4 |
6.3
9.0 |
6.5
9.4 |
6.3
9.0 |
5.8
8.3 |
6.4
9.2 |
5.8
8.5 |
|
04
05 |
11.0
12.4 |
12.5
13.9 |
12.0
15.4 |
13.0
15.9 |
12.0
16.2 |
11.5
15.0 |
12.9
14.5 |
12.0
16.1 |
13.3
16.5 |
12.1
16.6 |
13.4
16.6 |
12.1
16.6 |
11.8
15.8 |
11.9
15.2 |
11.8
15.7 |
|
06
07 |
14.9
19.9 |
17.2
22.4 |
19.3
25.2 |
19.2
25.4 |
21.3
28.6 |
19.8
27.2 |
17.9
23.3 |
20.1
26.2 |
19.9
26.3 |
21.7
29.6 |
20.1
26.6 |
21.8
29.8 |
20.3
27.9 |
20.9
25.6 |
20.6
28.2 |
|
08
09 |
29.9
40.9 |
33.7
47.3 |
37.5
51.0 |
37.8
51.5 |
37.9
51.4 |
35.5
47.9 |
35.2
49.3 |
38.2
51.9 |
38.6
51.7 |
38.6
52.4 |
39.0
51.8 |
39.0
52.8 |
36.5
48.2 |
36.6
51.3 |
36.1
48.4 |
