传动比i |
高速轴输入转速n1/r・min-1 |
型号 | |||||||
|
SB120 |
SB150 |
SB180 |
SB220 |
SB270 |
SB330 |
SB390 |
SB450 | ||
|
高速轴额定输出转矩T2/N・m | |||||||||
|
5.5 |
1500 |
4.65 |
8.07 |
13.3 |
21.8 |
38.9 |
― |
― |
― |
|
1000 |
3.10 |
5.38 |
8.86 |
14.5 |
26.0 |
― |
― |
― | |
|
750 |
2.33 |
4.04 |
6.65 |
10.9 |
19.5 |
― |
― |
― | |
|
7 |
1500 |
3.68 |
6.70 |
10.3 |
18.1 |
32.0 |
52.3 |
75.9 |
― |
|
1000 |
2.45 |
4.47 |
6.87 |
12.1 |
21.3 |
34.9 |
50.6 |
― | |
|
750 |
1.84 |
3.35 |
5.15 |
9.05 |
16.0 |
26.1 |
38.0 |
― | |
|
9 |
1500 |
2.95 |
5.40 |
8.59 |
15.2 |
27.9 |
37.9 |
64.9 |
94.5 |
|
1000 |
1.97 |
3.60 |
5.73 |
10.1 |
18.6 |
25.3 |
43.3 |
63.0 | |
|
750 |
1.48 |
2.70 |
4.30 |
7.60 |
14.0 |
18.9 |
32.4 |
47.3 | |
|
11 |
1500 |
2.42 |
3.74 |
7.54 |
12.5 |
24.4 |
38.4 |
58.9 |
80.6 |
|
1000 |
1.61 |
2.49 |
5.03 |
8.34 |
16.3 |
25.6 |
39.3 |
53.7 | |
|
750 |
1.21 |
1.87 |
3.77 |
6.25 |
12.2 |
19.2 |
29.5 |
40.3 | |
|
14 |
1500 |
2.04 |
3.87 |
6.05 |
9.96 |
18.7 |
31.7 |
44.6 |
68.8 |
|
1000 |
1.36 |
2.58 |
4.03 |
6.64 |
12.5 |
21.1 |
29.7 |
45.8 | |
|
750 |
1.02 |
1.94 |
3.03 |
4.98 |
9.37 |
15.9 |
22.3 |
34.4 | |
|
17 |
1500 |
1.50 |
2.93 |
4.99 |
9.05 |
15.7 |
26.3 |
39.2 |
56.6 |
|
1000 |
0.99 |
1.95 |
3.33 |
6.03 |
10.4 |
17.6 |
26.2 |
37.8 | |
|
750 |
0.75 |
1.47 |
2.50 |
4.53 |
7.80 |
13.2 |
19.6 |
28.3 | |
|
23 |
1500 |
1.07 |
2.32 |
3.71 |
6.68 |
12.2 |
16.7 |
26.0 |
37.6 |
|
1000 |
0.71 |
1.55 |
2.47 |
4.45 |
8.11 |
11.1 |
17.3 |
25.1 | |
|
750 |
0.53 |
1.16 |
1.85 |
3.34 |
6.10 |
8.36 |
13.0 |
18.8 | |
|
29 |
1500 |
― |
1.35 |
2.56 |
4.92 |
9.63 |
15.4 |
22.7 |
29.0 |
|
1000 |
― |
0.90 |
1.71 |
3.28 |
6.42 |
10.2 |
15.1 |
19.4 | |
|
750 |
― |
0.68 |
1.28 |
2.46 |
4.81 |
7.68 |
11.4 |
14.5 | |
|
35 |
1500 |
― |
― |
― |
― |
6.94 |
12.3 |
19.1 |
27.9 |
|
1000 |
― |
― |
― |
― |
4.63 |
8.18 |
12.7 |
18.6 | |
|
750 |
― |
― |
― |
― |
3.47 |
6.13 |
9.53 |
14.0 | |
