YND系列圆柱齿轮减速机高速轴转动惯量（YB/T050-93） QQ：20275456
|
规格 |
公称传动比iN | ||||||||||||||
|
1.25 |
1.4 |
1.6 |
1.8 |
2 |
2.24 |
2.5 |
2.8 |
3.15 |
3.55 |
4 |
4.5 |
5 |
5.6 |
6.3 | |
|
转动惯量J1(kg・m2) | |||||||||||||||
|
80 |
0.00161 |
0.00142 |
0.00123 |
0.00110 |
0.00099 |
0.00087 |
0.00081 |
0.00073 |
0.00058 |
0.00051 |
0.00045 |
0.00037 |
0.00031 |
0.00026 |
|
|
100 |
0.00579 |
0.00517 |
0.00446 |
0.00398 |
0.00354 |
0.00315 |
0.00292 |
0.00253 |
0.00178 |
0.00154 |
0.00131 |
0.00118 |
0.00093 |
0.00083 |
0.00070 |
|
125 |
0.0165 |
0.0148 |
0.0127 |
0.0114 |
0.0102 |
0.00912 |
0.00859 |
0.00736 |
0.00556 |
0.00483 |
0.00413 |
0.00368 |
0.00291 |
0.00244 |
0.00215 |
|
160 |
0.0505 |
0.0448 |
0.0373 |
0.0383 |
0.0342 |
0.0305 |
0.0286 |
0.0254 |
0.0183 |
0.0158 |
0.0144 |
0.0123 |
0.00961 |
0.00852 |
0.00695 |
|
200 |
0.173 |
0.155 |
0.131 |
0.119 |
0.106 |
0.0940 |
0.0885 |
0.0761 |
0.0562 |
0.0510 |
0.0430 |
0.0382 |
0.0292 |
0.0262 |
0.0224 |
|
250 |
0.523 |
0.467 |
0.399 |
0.360 |
0.323 |
0.288 |
0.271 |
0.233 |
0.179 |
0.156 |
0.134 |
0.121 |
0.0957 |
0.0790 |
0.0710 |
|
280 |
|
|
0.726 |
0.651 |
0.580 |
0.514 |
0.482 |
0.431 |
0.331 |
0.286 |
0.244 |
0.218 |
0.169 |
0.140 |
0.132 |
|
320 |
|
|
1.36 |
1.23 |
1.10 |
0.977 |
0.919 |
0.815 |
0.604 |
0.510 |
0.470 |
0.402 |
0.311 |
0.276 |
0.225 |
|
360 |
|
|
2.50 |
2.29 |
1.97 |
1.62 |
1.52 |
1.38 |
1.05 |
0.891 |
0.805 |
0.710 |
0.543 |
0.468 |
0.408 |
|
400 |
|
|
|
|
3.32 |
2.79 |
2.63 |
2.33 |
1.86 |
1.55 |
1.39 |
1.19 |
0.957 |
0.830 |
0.723 |
|
450 |
|
|
|
|
5.82 |
5.09 |
4.62 |
3.93 |
3.16 |
2.72 |
2.36 |
2.06 |
1.71 |
1.46 |
1.28 |
|
500 |
|
|
|
|
9.71 |
8.52 |
7.91 |
6.73 |
5.42 |
4.70 |
4.01 |
3.6 |
2.99 |
2.53 |
2.25 |
|
560 |
|
|
|
|
11.085 |
15.254 |
13.667 |
12.203 |
10.847 |
9.62 |
8.23 |
6.54 |
5.88 |
4.78 |
3.95 |
|
影响系数Kf | |||||||||||||||
|
- |
1.05 |
1.05 |
1.05 |
1.05 |
1.05 |
1.05 |
1.05 |
1.1 |
1.1 |
1.1 |
1.1 |
1.5 |
1.5 |
1.5 |
1.5 |
