齿轮减速机

YN系列圆柱齿轮减速机传动比YB/T050-93

发布日期：2023-12-28 18:45 浏览次数：

YN系列圆柱齿轮减速机传动比YB/T050-93(图1) Mobile:13331225020

YN系列圆柱齿轮减速机传动比（YB/T050-93）

gelufu.com

YND减速器传动比
规格
公称传动比iN
1.25
1.4
1.6
1.8
2.0
2.24
2.5
2.8
3.15
3.55
4
4.5
5
5.6
6.3
实际传动比i
80
1.235
1.375
1.621
1.815
2.040
2.304
2.455
2.800
3.222
3.529
4.067
4.421
5.059
5.526
6.353
100
1.235
1.375
1.621
1.815
2.040
2.304
2.455
2.800
3.222
3.571
4.053
4.389
5.063
5.467
6.222
125
1.257
1.394
1.633
1.821
2.038
2.292
2.478
2.762
3.158
3.500
4.053
4.588
4.938
5.667
6.176
160
1.235
1.375
1.621
1.815
2.040
2.304
2.455
2.783
3.143
3.579
3.944
4.421
5.059
5.500
6.294
200
1.235
1.375
1.621
1.815
2.040
2.304
2.455
2.864
3.200
3.474
4.000
4.588
5.056
5.529
6.267
250
1.257
1.394
1.633
1.821
2.038
2.292
2.435
2.762
3.158
3.571
4.053
4.588
4.938
5.688
6.133
280
-
-
1.621
1.815
2.040
2.304
2.455
2.800
3.222
3.529
3.944
4.563
5.063
5.688
6.133
320
-
-
1.621
1.815
2.040
2.304
2.455
2.783
3.143
3.579
3.944
4.421
5.059
5.588
6.294
360
-
-
1.606
1.774
1.966
2.222
2.480
2.783
3.143
3.526
4.059
4.444
5.125
5.444
6.188
400
-
-
-
-
2.036
2.269
2.542
2.864
3.174
3.571
4.053
4.588
5.063
5.529
6.333
450
-
-
-
-
1.966
2.222
2.480
2.783
3.143
3.579
4.059
4.588
5.063
5.750
6.200
500
-
-
-
-
2.038
2.292
2.435
2.762
3.158
3.571
4.053
4.389
4.944
5.625
6.133
560
-
-
-
-
2.040
2.304
2.455
2.870
3.091
3.500
3.944
4.563
4.944
5.688
6.133
YNL、YNLO、YNLA减速器传动比
规格
公称传动比iN
7.1
8
9
10
11.2
12.5
14
16
18
20
实际传动比i
192
6.847
7.797
8.894
10.235
11.211
12.446
14.340
15.590
17.944
20.530
215
7.068
7.737
8.772
9.925
11.136
12.817
14.206
15.561
17.984
20.410
240
7.227
7.698
8.782
10.106
11.201
12.711
14.387
15.581
17.799
20.531
272
7.000
8.014
8.767
9.983
11.083
12.756
14.526
15.582
17.503
19.500
305
7.202
7.789
8.680
9.925
11.000
12.342
14.291
16.180
18.623
20.040
340
7.374
7.855
8.933
10.036
11.360
12.332
14.088
15.458
17.800
20.222
385
7.242
7.714
8.745
9.878
11.248
12.397
13.895
15.590
17.839
20.533
430
7.277
7.832
8.787
9.925
11.136
12.817
14.035
15.873
18.304
20.110
480
6.873
7.909
9.227
10.311
11.193
12.889
14.118
16.194
17.843
19.941
545
6.984
7.794
8.745
9.878
11.083
12.756
14.526
15.882
18.094
19.941
610
7.202
7.652
8.680
9.925
11.224
12.594
14.291
16.180
17.411
-
680
7.314
7.791
8.887
10.227
11.508
12.605
14.087
16.295
18.490
-
770
7.242
7.714
8.745
9.959
11.248
12.809
14.117
15.823
18.105
-
860
7.018
7.832
8.787
9.938
11.224
12.594
14.496
15.873
18.304
-
960
7.014
7.856
8.896
10.023
11.109
12.500
14.184
16.059
18.098
-
1080
6.878
7.953
8.876
9.959
11.248
12.809
14.526
16.421
18.118
-
1210
7.093
8.081
8.586
9.739
11.136
12.594
14.291
15.477
17.436
-
1360
7.133
8.126
8.656
10.119
10.900
12.342
13.909
16.089
17.436
-
YNS、YNSO、YNSA减速器传动比
规格
公称传动比iN
20
22.4
25
28
31.5
35.5
40
45
50
56
63
71
80
90
100
实际传动比i
352
-
21.519
24.504
27.953
32.168
35.235
39.115
45.070
51.223
55.796
64.222
73.486
80.991
88.475
96.730
395
-
22.213
24.316
27.569
31.192
34.998
38.789
43.522
50.094
54.768
62.310
72.206
78.600
90.469
102.426
440
-
21.972
24.635
28.102
32.339
35.844
38.910
44.041
49.975
54.122
62.429
71.319
77.013
88.681
100.938
497
-
22.301
25.188
27.553
31.376
34.831
39.081
44.504
51.224
56.003
61.723
68.774
79.109
91.056
98.193
555
-
21.777
24.596
27.411
31.342
34.737
38.975
45.129
51.093
54.983
62.183
71.573
82.143
89.947
98.639
620
-
22.649
25.309
28.785
32.339
35.105
39.735
43.523
49.721
54.557
62.824
71.373
80.294
89.736
96.770
705
-
21.466
24.245
27.485
31.044
34.831
39.664
43.715
48.997
55.796
63.845
73.486
79.895
88.054
96.269
790
19.060
21.527
24.614
27.617
31.192
34.998
39.581
45.558
51.117
55.973
64.544
73.241
82.383
83.425
-
880
19.6, , 31
22.649
25.103
29.287
32.727
35.526
38.912
44.808
50.420
57.835
63.725
71.219
77.894
88.280
-
995
19.202
21.688
24.496
27.485
31.044
34.831
39.664
45.654
49.914
56.839
62.644
71.369
81.173
87.525
-
1110
18.712
21.395
24.165
27.411
31.342
35.165
39.770
45.129
51.093
54.983
62.183
71.573
82.445
88.908
-
1240
20.170
21.726
24.080
27.469
31.611
34.625
38.961
43.543
49.306
57.031
63.281
71.808
80.673
86.996
-
1400
19.916
22.416
23.878
27.069
30.573
34.816
39.646
43.695
48.975
56.629
64.798
73.486
81.176
91.430
-
1570
19.298
21.721
24.241
27.198
30.720
34.468
39.673
44.868
49.131
55.973
64.544
73.241
77.806
88.425
-
1760
20.086
21.710
24.316
27.397
30.365
34.168
38.772
43.904
49.706
56.628
62.482
70.416
76.911
88.093
-
YNF、YNFO、YNFA减速器传动比
规格
公称传动比iN
100
112
125
140
160
180
200
224
250
280
315
355
400
450
500
实际传动比i
395
-
112.362
124.535
135.763
152.328
175.331
203.509
222.495
257.626
279.029
315.906
363.611
418.359
476.353
514.382
440
-
116.677
129.321
140.648
152.677
173.248
197.125
213.481
243.883
282.097
305.025
351.241
385.423
444.555
512.515
497
-
115.128
127.808
139.992
157.072
180.982
208.312
229.586
249.593
272.880
305.852
352.038
402.823
448.841
490.319
555
-
110.520
122.493
137.438
155.436
178.909
207.157
226.485
260.686
285.453
323.179
367.979
395.990
431.052
489.130
620
-
113.117
128.035
141.911
155.440
176.384
201.502
218.222
251.285
275.725
316.273
353.465
407.715
440.265
500.176
705
-
110.641
125.993
139.869
159.277
183.329
202.052
220.903
254.261
284.983
311.571
343.390
382.620
437.816
503.611
790
98.502
110.520
122.493
138.534
155.436
179.979
207.157
235.069
257.403
291.421
313.605
355.052
408.668
471.245
507.117
880
102.642
111.421
122.043
138.139
155.440
178.992
204.482
228.527
250.754
287.630
326.770
310.798
408.565
459.635
531.655
995
97.566
109.470
124.660
141.957
156.454
178.163
205.067
229.846
253.319
276.952
316.905
359.397
402.823
437.952
498.950
1110
98.502
110.520
124.005
140.243
161.421
182.560
207.157
226.829
261.094
295.601
323.685
373.249
401.662
451.797
512.671
1240
101.155
109.806
120.275
135.338
153.251
171.272
197.222
223.795
256.706
290.633
320.235
360.899
417.449
456.576
506.612
1400
96.088
107.811
122.771
139.806
154.084
177.352
201.132
219.897
254.261
284.983
324.676
367.025
416.237
473.412
522.347
1570
97.009
108.846
123.099
139.219
158.608
179.979
207.157
226.839
256.819
291.421
313.605
339.626
391.631
451.119
519.242
1760
97.843
110.793
124.669
136.555
155.573
173.867
197.293
222.346
257.186
291.176
323.086
373.710
412.339
463.245
533.199
