输入轴
转速
(r・min) |
减速器
型号 |
公称传动比 | ||||||||
|
8.0 |
10.0 |
12.5 |
16.0 |
20.0 |
25.0 |
31.5 |
40.0 |
50.0 | ||
|
输出轴上的最大短时容许转矩 (kN・m) | ||||||||||
|
600 |
PJ250 |
|
|
|
|
|
|
|
|
|
|
PJ350 |
|
|
|
|
|
|
|
|
| |
|
PJ400 |
5.4 |
6.0 |
10.1 |
11.1 |
13.4 |
14.1 |
15.1 |
15.8 |
16.3 | |
|
PJ500 |
18.0 |
20.5 |
22.5 |
24.0 |
25.0 |
25.0 |
25.5 |
25.9 |
27.0 | |
|
PJ650 |
33.5 |
37.0 |
41.0 |
46.0 |
56.5 |
59.0 |
60.0 |
62.5 |
63.5 | |
|
PJ750 |
52.0 |
60.0 |
67.5 |
75.5 |
82.0 |
83.0 |
85.0 |
89.0 |
95.0 | |
|
PJ850 |
69.0 |
81.0 |
92.6 |
101.2 |
111.2 |
113.4 |
116.8 |
122.0 |
122.8 | |
|
PJ1000 |
107.0 |
120.0 |
142.0 |
150.0 |
187.0 |
190.0 |
196.0 |
205.0 |
209.0 | |
|
750 |
PJ250 |
2.5 |
2.8 |
3.0 |
3.1 |
3.2 |
3.2 |
3.3 |
3.4 |
3.4 |
|
PJ350 |
6.4 |
6.6 |
6.8 |
7.0 |
7.3 |
7.4 |
7.6 |
7.9 |
8.0 | |
|
PJ400 |
8.1 |
9.2 |
9.6 |
10.6 |
12.9 |
13.5 |
14.9 |
15.7 |
16.2 | |
|
PJ500 |
16.5 |
19.0 |
21.0 |
23.5 |
24.5 |
25.0 |
25.5 |
26.5 |
27.0 | |
|
PJ650 |
29.0 |
34.0 |
38.0 |
43.0 |
52.5 |
55.5 |
59.5 |
61.5 |
62.5 | |
|
PJ750 |
47.5 |
54.5 |
62.0 |
70.0 |
80.0 |
81.0 |
84.0 |
88.0 |
89.0 | |
|
PJ850 |
|
|
90.0 |
95.6 |
108.0 |
109.4 |
115.2 |
120.0 |
121.8 | |
|
PJ1000 |
95.4 |
110.0 |
125.0 |
147.0 |
181.0 |
182.0 |
191.0 |
202.0 |
206.0 | |
|
1000 |
PJ250 |
2.3 |
2.6 |
2.9 |
3.0 |
3.1 |
3.2 |
3.2 |
3.4 |
3.4 |
|
PJ350 |
6.1 |
6.4 |
6.6 |
6.8 |
7.2 |
7.3 |
7.5 |
7.8 |
7.9 | |
|
PJ400 |
6.9 |
7.95 |
8.85 |
9.95 |
12.0 |
12.7 |
14.1 |
15.5 |
16.0 | |
|
PJ500 |
14.5 |
17.0 |
19.0 |
21.0 |
24.0 |
24.0 |
25.0 |
26.0 |
26.0 | |
|
PJ650 |
27.0 |
29.5 |
34.0 |
38.5 |
46.0 |
55.0 |
57.0 |
60.5 |
62.0 | |
|
PJ750 |
|
47.5 |
56.0 |
62.0 |
76.0 |
79.0 |
81.0 |
85.5 |
87.0 | |
|
PJ850 |
|
|
|
|
103.0 |
105.6 |
110.4 |
116.4 |
118.4 | |
|
PJ1000 |
|
|
|
129.0 |
159.0 |
172.0 |
182.0 |
193.0 |
200.0 | |
|
1250 |
PJ250 |
2.2 |
2.5 |
2.7 |
3.0 |
3.1 |
3.1 |
3.2 |
3.3 |
3.4 |
|
PJ350 |
6.1 |
6.4 |
6.4 |
6.6 |
7.0 |
7.1 |
7.4 |
7.7 |
7.8 | |
|
PJ400 |
|
|
|
|
|
|
|
|
| |
|
PJ500 |
|
|
|
|
|
|
|
|
| |
|
PJ650 |
|
|
|
|
|
|
|
|
| |
|
PJ750 |
|
|
|
|
|
|
|
|
| |
|
PJ850 |
|
|
|
|
98.2 |
101.0 |
106.4 |
113.4 |
116.4 | |
|
PJ1000 |
|
|
|
|
|
155.0 |
178.0 |
187.6 |
195.0 | |
|
1500 |
PJ250 |
2.0 |
2.3 |
2.6 |
2.9 |
3.1 |
3.1 |
3.2 |
3.3 |
3.4 |
|
PJ350 |
5.8 |
6.1 |
6.1 |
6.4 |
6.8 |
6.9 |
7.1 |
7.4 |
7.7 | |
|
PJ400 |
5.9 |
6.7 |
7.7 |
8.6 |
10.6 |
11.4 |
12.8 |
14.9 |
15.7 | |
|
PJ500 |
|
14.0 |
18.0 |
18.5 |
22.0 |
23.0 |
24.0 |
25.0 |
25.5 | |
|
PJ650 |
|
|
|
32.0 |
40.0 |
43.0 |
52.5 |
57.5 |
59.0 | |
|
PJ750 |
|
|
|
|
63.5 |
69.0 |
76.5 |
81.0 |
83.5 | |
|
PJ850 |
|
|
|
|
|
|
|
|
| |
|
PJ1000 |
|
|
|
|
|
|
|
|
| |
