传仕600系列摆线针轮减速机4极减速机马达选用表（59、71、87） 格鲁夫减速机
|
减速比 |
频率 |
马达入力轴转速 |
减速机出力轴转速 |
|
59 |
50Hz |
1500R.P.M. |
25R.P.M. |
|
60Hz |
1800R.P.M. |
31 R.P.M. |
|
马达 |
50Hz |
60Hz |
传仕摆线
减速机型号 | ||||||
|
KW |
HP |
代码 |
输出扭矩
Kg.m/in.Ib |
容许输出轴
悬垂负荷
Kg/Ib |
安全
系数 |
输出扭矩
Kg.m/in.Ib |
容许输出轴
悬垂负荷
Kg/Ib |
安全
系数 | |
|
0.2 |
1/4 |
02 |
7.08/614 |
340/748 |
1.65 |
5.90/512 |
340/748 |
1.65 |
02-609-59 |
|
0.4 |
1/2 |
05 |
14.2/1232 |
550/1210 |
1.50 |
11.8/1024 |
550/1210 |
1.52 |
05-610-59 |
|
880/1936 |
3.42 |
880/1936 |
3.45 |
05-611-59 | |||||
|
0.75 |
1 |
1 |
26.6/2309 |
880/1936 |
1.83 |
22.1/1918 |
880/1936 |
1.84 |
1-611-59 |
|
1.5 |
2 |
2 |
53.1/4609 |
1295/2849 |
1.43 |
44.3/3845 |
1220/2684 |
1.44 |
2-613-59 |
|
1500/3300 |
1.87 |
1500/3300 |
1.89 |
2-614-59 | |||||
|
2.2 |
3 |
3 |
77.9/6762 |
1500/3300 |
1.27 |
64.9/5633 |
1500/3300 |
1.29 |
3-614-59 |
|
1600/3520 |
1.28 |
1600/3520 |
1.32 |
3-615-59 | |||||
|
2.2 |
3 |
3 |
77.9/6762 |
2000/4400 |
2.25 |
64.9/5633 |
1985/4367 |
2.23 |
3-616-59 |
|
3.4 |
5 |
5 |
131/11371 |
2090/4400 |
1.34 |
109/6461 |
1985/4367 |
1.32 |
5-616-59 |
|
2490/5478 |
1.97 |
2340/5148 |
1.95 |
5-617-59 | |||||
|
5.5 |
7.5 |
8 |
195/16926 |
2490/5478 |
1.32 |
162/14062 |
2340/5148 |
1.31 |
8-617-59 |
|
3330/7326 |
1.79 |
3140/6908 |
1.77 |
8-618-59 | |||||
|
7.5 |
10 |
10 |
266/23089 |
3300/7326 |
1.31 |
221/190183 |
3140/6908 |
1.30 |
10-618-59 |
|
4660/10252 |
2.07 |
4400/9680 |
2.07 |
10-619-59 | |||||
|
11 |
15 |
15 |
389/33765 |
4660/10252 |
1.41 |
325/28210 |
4400/9680 |
1.41 |
15-619-59 |
|
5700/12540 |
1.74 |
5410/11902 |
1.74 |
15-620-59 | |||||
|
15 |
20 |
20 |
531/46091 |
4660/10252 |
1.03 |
443/38452 |
4400/9680 |
1.03 |
20-619-59 |
|
5700/12540 |
1.27 |
5410/11902 |
1.28 |
20-620-59 | |||||
|
7265/15983 |
1.85 |
4400/9680 |
1.85 |
20-621-59 | |||||
|
18.5 |
25 |
25 |
655/56854 |
5700/12540 |
1.03 |
546/47393 |
5410/11902 |
1.04 |
25-620-59 |
|
7265/15983 |
1.50 |
6890/15158 |
1.50 |
25-621-59 | |||||
|
7640/16808 |
1.80 |
7250/15950 |
1.80 |
25-622-59 | |||||
|
22 |
30 |
30 |
779/67617 |
7265/15983 |
1.26 |
649/56333 |
6890/15158 |
1.26 |
30-621-59 |
|
7640/16808 |
1.52 |
7250/15950 |
1.51 |
30-622-59 | |||||
|
30 |
40 |
40 |
1062/92182 |
7640/16808 |
1.11 |
885/76818 |
7250/15950 |
1.11 |
40-622-59 |
格鲁夫减速机
|
减速比 |
频率 |
马达入力轴转速 |
减速机出力轴转速 |
|
71 |
50Hz |
1500R.P.M. |
21R.P.M. |
|
60Hz |
1800R.P.M. |
25 R.P.M. |
|
马达 |
50Hz |
60Hz |
传仕摆线
减速机型号 | ||||||
|
KW |
HP |
代码 |
输出扭矩
Kg.m/in.Ib |
容许输出轴
悬垂负荷
Kg/Ib |
安全
系数 |
输出扭矩
Kg.m/in.Ib |
容许输出轴
悬垂负荷
Kg/Ib |
安全
系数 | |
|
0.2 |
1/4 |
02 |
8.52/740 |
340/748 |
1.30 |
7.10/616 |
340/748 |
1.30 |
02-609-71 |
|
550/1210 |
2.45 |
550/1210 |
2.45 |
02-610-71 | |||||
|
0.4 |
1/2 |
05 |
17.0/1476 |
550/1210 |
1.22 |
14.2/1232 |
550/1210 |
1.22 |
05-610-71 |
|
880/1936 |
2.45 |
880/1936 |
2.45 |
05-611-71 | |||||
|
0.75 |
1 |
1 |
32.0/2778 |
880/1936 |
1.31 |
26.6/2309 |
880/1936 |
1.31 |
1-611-71 |
|
1000/2200 |
1.36 |
1000/2200 |
1.35 |
1-612-71 | |||||
|
1350/2970 |
2.40 |
1295/2849 |
2.43 |
1-613-71 | |||||
|
1.5 |
2 |
2 |
63.9/5546 |
1350/2970 |
1.20 |
53.2/4618 |
1295/2849 |
1.21 |
2-613-71 |
|
1500/3300 |
1.41 |
1500/3300 |
1.40 |
2-164-71 | |||||
|
1600/3520 |
1.45 |
1600/3520 |
1.45 |
2-615-71 | |||||
|
2000/4400 |
2.73 |
2000/4400 |
2.73 |
2-616-71 | |||||
|
2.2 |
3 |
3 |
93.7/8133 |
1600/3520 |
1.00 |
78.1/6779 |
1600/3520 |
1.00 |
3-615-71 |
|
2000/4400 |
1.86 |
2000/4400 |
1.86 |
3-616-71 | |||||
|
3.7 |
5 |
5 |
158/13714 |
2000/4400 |
1.10 |
131/11371 |
2000/4400 |
1.11 |
5-616-71 |
|
2680/5896 |
1.62 |
2490/5478 |
1.62 |
5-617-71 | |||||
|
5.5 |
7.5 |
8 |
234/20422 |
2680/5896 |
1.09 |
195/16926 |
2460/5478 |
1.09 |
8-617-71 |
|
3590/7898 |
1.34 |
3330/7326 |
1.33 |
8-618-71 | |||||
|
5020/11044 |
2.44 |
4660/10252 |
2.44 |
8-619-71 | |||||
|
7.5 |
10 |
10 |
320/27776 |
3590/7898 |
1.00 |
266/23089 |
3330/7326 |
1.00 |
10-618-71 |
|
5020/11044 |
1.79 |
4660/10252 |
1.79 |
10-619-71 | |||||
|
11 |
15 |
15 |
469/40709 |
5020/11044 |
1.22 |
391/33939 |
4660/10252 |
1.22 |
15-619-71 |
|
减速比 |
频率 |
马达入力轴转速 |
减速机出力轴转速 |
|
87 |
50Hz |
1500R.P.M. |
17R.P.M. |
|
60Hz |
1800R.P.M. |
21 R.P.M. |
|
马达 |
50Hz |
60Hz |
传仕摆线
减速机型号 | ||||||
|
KW |
HP |
代码 |
输出扭矩
Kg.m/in.Ib |
容许输出轴
悬垂负荷
Kg/Ib |
安全
系数 |
输出扭矩
Kg.m/in.Ib |
容许输出轴
悬垂负荷
Kg/Ib |
安全
系数 | |
|
0.2 |
1/4 |
02 |
10.4/903 |
340/748 |
1.25 |
8.70/755 |
340/748 |
1.20 |
02-609-87 |
|
550/1210 |
2.45 |
550/1210 |
2.45 |
02-610-87 | |||||
|
0.4 |
1/2 |
05 |
20.9/1814 |
550/1210 |
1.22 |
17.4/1510 |
550/1210 |
1.22 |
05-610-87 |
|
880/1936 |
2.33 |
880/1936 |
2.33 |
05-611-87 | |||||
|
0.75 |
1 |
1 |
39.2/3402 |
880/1936 |
1.24 |
32.6/2830 |
880/1936 |
1.24 |
1-611-87 |
|
1364/3001 |
1.95 |
1360/2992 |
1.96 |
1-613-87 | |||||
|
1.5 |
2 |
2 |
78.3/6796 |
1500/3300 |
1.30 |
65.2/5659 |
1500/3300 |
1.31 |
2-614-87 |
|
1600/3520 |
1.31 |
1600/3520 |
1.33 |
2-615-87 | |||||
|
2050/4510 |
2.23 |
2000/4400 |
2.23 |
2-616-87 | |||||
|
2.2 |
3 |
3 |
115/9982 |
2050/4510 |
1.52 |
95.7/8342 |
2000/4400 |
1.52 |
3-616-87 |
|
2900/6380 |
2.20 |
2660/5852 |
2.20 |
3-617-87 | |||||
|
3.7 |
5 |
5 |
193/16752 |
2900/6380 |
1.31 |
161/13975 |
2660/5852 |
1.31 |
5-617-87 |
|
3760/8272 |
2.03 |
3540/7788 |
2.03 |
5-618-87 | |||||
|
5.5 |
7.5 |
8 |
287/24912 |
3760/8272 |
1.34 |
239/20745 |
3540/7788 |
1.34 |
8-618-87 |
|
5260/11572 |
2.13 |
4950/10890 |
2.13 |
8-619-87 | |||||
|
7.5 |
10 |
10 |
392/34026 |
5260/11572 |
1.56 |
326/28297 |
4950/10890 |
1.56 |
10-619-87 |
|
6600/14520 |
1.83 |
6030/13266 |
1.81 |
10-620-87 | |||||
|
11 |
15 |
15 |
574/49823 |
5260/11572 |
1.06 |
478/41490 |
4950/10890 |
1.06 |
15-619-87 |
|
6600/14520 |
1.24 |
6030/13266 |
1.24 |
15-620-87 | |||||
|
8410/18502 |
1.65 |
7680/16896 |
1.66 |
15-621-87 | |||||
|
8840/19448 |
1.99 |
8090/17798 |
1.99 |
15-622-87 | |||||
|
15 |
15 |
20 |
783/67964 |
8410/18502 |
1.22 |
652/56594 |
7680/16896 |
1.21 |
20-621-87 |
|
8840/19448 |
1.46 |
8090/17798 |
1.46 |
20-622-87 | |||||
|
18.5 |
20 |
25 |
966/83849 |
8840/19448 |
1.18 |
805/69874 |
8090/17798 |
1.18 |
25-622-87 |
